• 400 MHz (9.39 T) NMR Spectrometer  AVANCE II Bruker

• ■
  BBFO probe Z-gradient, 5mm – double resonance broadband probe optimized for X-nuclei detection. The inner coil is tunable over a frequency range that enables observation of nuclei between 97Mo and 31P, and 19F. The outer coil is optimized for 1H decoupling and observation. Temperature range: -80 oC to +130 oC.
• ■
  BBI probe, H-BB, Z-gradient, 5 mm - double resonance broadband inverse probe optimized for 1H detection. The outer coil is tuneable over a frequency range that permits decoupling of nuclei between 109Ag-31P. This probe is used for experiments like HSQC, HMQC, and HMBC. Temperature range:-150 oC to +180 oC.

• 500 MHz (11.74 T) NMR Spectrometer AVANCE III Bruker

• ■
  BBO probe, 1H-19F,(31P-15N)+19F,D, Z-gradient, 5 mm - double resonance broadband probe optimized for X-nuclei detection. The inner coil is tunable over a frequency range that enables observation of nuclei between 97Mo and 31P, and 19F. The outer coil is optimized for 1H decoupling and observation. This probe also enable recording of 1H-{19F}, 19F-{1H} and X-{19F}, 19F-{X} correlation experiments. Temperature range: -150oC to +150oC.
• ■
  TXI probe, H-C/N,D, 5 mm, Z-gradient. Triple resonance inverse probe optimized for 1H detection with the outer coil tuneable for 13C or 15N. Triple resonance probe can be used to record triple resonance experiments of biological macromolecules labelled with 13C and 15N. Temperature range: -150oC to +150oC.

• 700 MHz (16.44 T) NMR Spectrometer AVANCE III Bruker

• ■
  QCI-P probe, 1H/13C/15N/31P, 5 mm, Z-gradient- Quadruple Resonance CryoProbeTM - a proton-optimized quadruple resonance NMR inverse probe - increases sensitivity about four times on 1H and 13C compared to a room temperature QXI probe. Four fully independent channels of this probe enable simultaneous decoupling on multiple nuclei such as 13C, 31P and 15N. It is ideally suited to the study of RNA/ DNA and proteins, whilst also enabling research on small molecules and metabolomic samples. Temperature range: 0oC to +80oC
• ■
  BBO probe, BB-H-D, 5 mm, Z-gradient -double resonance broadband probe optimized for X-nuclei detection. The inner coil is tunable over a frequency range that enables observation of nuclei between 97Mo and 31P, and 19F. The outer coil is optimized for 1H decoupling and observation. Temperature range: -150oC to +150oC.
• ■
  TXI probe, H-C/N,D, 5 mm, Z-gradient
• ■
  TXI probe, H-P/C,D, 5 mm, Z-gradient
• ■
  Triple resonance inverse probes optimized for 1H detection while the outer coils are tuneable for 13C and 15N or 13C and 31P. Triple Resonance Probes can be used to record triple resonance experiments of proteins and nucleic acids labelled with 13C and
• ■
  15N. Temperature range: -150oC to +150oC.
• ■
  SampleCaseTM is fully automated 24 sample changer that together with IconNMR™ allows fully automated acquisition and processing.

• Spectropolarimiter circular dichroism (CD) Jasco J-815 S

• Circular Dichroism (CD) spectropolarimiter from JASCO. The system is designed to measure CD in UV/Vis region but it has many optionally available measurement modes such as measurement of optical rotatory dispersion (ORD), linear dichroism (LD) or fluorescence.
• Hardware Specifications

• ○
  Wavelength range CD: 180-900 nm
• ○
  Wavelength range ORD: 190- 600 nm, range of angle of rotation +/-35°
• ○
  Wavelength range LD: 200-800 nm
• ○
  Wavelength range for fluorescence emission measurement: 200-800 nm

• Spektrofotometr UV VIS Jasco V-650:

• Double beam UV VIS spectrophotometer working in wide range of wavelength (190-900 nm) with a single monochromator and photomultiplier tube detector.
• Enables accurate measurements of low concentration samples with excellent linearity up to an absorbance of 4. Graphical user interface is available including Spectra ManagerTM II software that allow full system control and advanced data processing.
• Accessories such as automated cell changers and programmable temperature control systems allow full control by the Spectra Manager II.

• High Performance Liquid Chromatography system  Agilent Tech 1260 Infinity

The system is equipped with variable volume autosampler, thermostatted column compartment, diode-array detector, multiple wavelength detector, fluorescence detector, fraction collector, degasser and automatic purge valve integrated into pump module.
